CR8 Two-in-one Spectrophotometer

  • CR8

  • 460g

  • 81X71X214mm

Availability:
Quantity:

CR8 Two-in-one Spectrophotometer and Spectrocolorreader

CR8 realizes the two-in-one spectrophotometer and spectrocolorreader, It uses a built-in silicon photodiode array (dual-row 24 groups) sensor, an imported white board, and the repeat ability ΔE*ab can be easily controlled within 0.04. CR8's powerful performance configuration and excellent inter-instrument error make color measurement more professional, while also ensuring the consistency of measurement data of multiple devices. The CR8 spectrocolorreader takes into account the measurement speed and the convenience of operation at the same time. The color can be controlled through the PC-side software, and it can also be seamlessly connected to the mobile device through Bluetooth. It greatly expands the application space of the colorimeter, and makes the traditional colorimeter glow with a different application charm.

Product Features


1. Adopt full-band balanced LED light source

The full-band balanced LED light source ensures sufficient spectral distribution in the visible light range, avoids the lack of spectrum of white LEDs in a specific band, and ensures the measurement speed of the instrument and the accuracy of the measurement results.

2. Grating Spectrophotometric technology

Using grating spectrophotometric technology, it has higher resolution and makes color measurement more accurate.

3. Fast charging

Special fast charging method, low-voltage reminder to charge or use of off-hours to charge, to ensure the capacity and life of the battery (note: frequent repeated charging of the battery is more harmful).


4. Novel and fashionable appearance design based on ergonomics

The position of the hand grip and the measurement button are carefully designed to meet different gripping habits. The smooth and fine surface is derived from the art of high-precision appearance processing.


5.  Customize a single measuring aperture to accurately meet the needs of sample measurement

Spectrocolorreader CR8 (Professional) can choose Ø8mm or Ø4mm platform aperture according to your needs to meet your sample measurement needs.

6. Diversified data display

SpectrocolorreaderCR8 (Professional)can intuitively display reflectance (reflectance at 3 specific wavelength specified by the user) , sample chromaticity value, color difference value/graph, pass/fail result, color simulation, color offset and other data .It is convenient to view and also greatly improves the user's work efficiency.

7. Use whatever you want

It can be used alone, 3.5inch true color screen can check data at any time, cooperate with SQCX quality management software to facilitate quality monitoring and color data management, with APP to synchronize data at any time, and more application scenarios are waiting for you to discover.



ModelCR8 (Professional)



Optical geometry

D/8 (diffuse illumination, 8° direction reception)
SCI measurement
Comply with standard CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7


Characteristics

Customized single measurement aperture for accurate color difference control in plastic and electronic, paint and ink, textile and garment printing and dyeing, printing, ceramics and other industries
Integrating sphere sizeΦ40mm
Light sourceCombined full-spectrum LED light source
Spectroscopic methodPlanar grating
SensorSilicon photodiode arrays (dual row 32 groups)
Wavelength range400~700nm
Wavelength interval10nm
Semiband Bandwidth10nm


Measurement range

L:0~120
Reflectivity: the instrument can test the reflectivity at 3 specific wavelengths specified by the user (default 440nm, 550nm, 600nm), APP can realize the full-band wavelength display
Measurement apertureSingle aperture: Φ8mm ( Φ4mm optional)
Focusing methodFixed Focus
Specular component

SCI

Color spaceCIE LAB,XYZ,Yxy,LCh
Color difference formulaΔE*ab,ΔE*00
Other colorimetric indexsMultiple colorimetric indexs are realized through APP
Observer angle10°
IlluminantD65,A,F2(CWF)
Displayed dataReflectivity(at 3 specific wavelengths specified by the user)chromaticity value, color difference value/graph, pass/fail result, color simulation, color offset
Display Accuracy0.01
Measurement timeApprox. 1.5s
RepeatabilityChromaticity value: MAV/SCI, ΔE*ab within 0.04 (When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Inter-instrument errorMAV/SCI, within ΔE*ab 0.35(Average for 12 BCRA Series II color tiles)
Measurement methodSingle measurement, average measurement (2~99 times)
Locating methodStabilizer locating
SizeLxWxH=81X71X214mm
WeightAbout 460g
Battery powerLithium battery, 6000 times in 8 hours
Illuminant life span5 years, more than 3 million times measurements
DisplayTFT true color 3.5inch, capacitive touch screen
Data portUSB, Bluetooth® 5.0
Data storage500 standard samples, 1,0000 samples , APP mass storage
LanguageSimplified Chinese, English, Traditional Chinese
Operating temperature range0~40℃, 0~85%RH (no condensation), altitude< 2000m
Storage temperature range-20~50℃, 0~85%RH (no condensation)
StandardPower adapter, data cable, manual, SQCX quality management software


Accessories

(official website download), black and white calibration box, protective cover, wrist strap, single aperture: Ø8mm (optional Ø4mm) platform aperture, MOBCCS APP (official website download)
Optional AccessoriesUSB micro printer, powder test box, Bluetooth micro printer,holder base
NotesTechnical parameters are for reference only, subject to the actual sales of products


Application

分光仪CR8详情页 (13)
