Laboratory Liofilization Machine Fruit Vacuum Freeze Drying Equipment Freeze Dryer Vacuum

Beachtop OKLG-10 Scientific Pharmaceutical Small Mini Vacuum Laboratory Freeze Dryer
  • OKLG-12A

  • Moreshine

  • OKLG-10A/OKLG-10B/OKLG-10C/OKLG-10D/OKLG-10E

  • AC220V 50Hz

  • 1300W

  • 70KG

  • 600x558x390mm

Availability:
Quantity:

Laboratory liofilization machine fruit vacuum freeze drying equipment freeze dryer vacuum


Moreshine vacuum freeze-drying machines are widely used in fields such as biological research, chemical engineering, and food. Freeze dried items are easy to store for a long time, and can be restored to their pre freeze-dried state and maintain their original biochemical characteristics after adding water.Moreshine OKLG-12 series freeze-drying machine is a vertical freeze-drying machine with shelf heating and programmable functions, which can be used in laboratories or small-scale production. It can be customized to meet various freeze-drying requirements in the laboratory.


Product Feature

1.LCD display microcomputer intelligent control

2.Acrylic vacuum cover

3.The highly transparent aviation acrylic material is not easy to crack, and the freeze-drying process of the material can be clearly observed

4.The vacuum grease is used for good adhesion to ensure the vacuum degree of the instrument


photobankphotobank (5)photobank (7)photobank (3)

photobank (1)

photobank (4)

photobank (2)

photobank (6)


Model

OKLG-10A

OKLG-10B

OKLG-10C

OKLG-10D

OKLG-10E

Specification

Standard

Manual gland type

Multi-manifold type

Multi-manifold gland type

T-frame type

Freeze-dried area

0.12m2

0.08m2

0.12m2

0.08m2

/

cold trap temperature

-60°C

Water catch KG/batch

4

Standard vacuum

≤5Pa (no load)

Ultimate vacuum

2PA

Material tray

200mm total 4 layers

180mm total 3 layers

200mm total 4 layers

180mm total 3 layers

Configure 24 drying bottle ports

Total power

Host 680Ww ((standard 37OW vacuum pump)

Host weight

70kg

Dimensions

600x558x390mm

power supply

AC220V 5OHz

Applicable environment

Ambient temperature≤30°C

Machine running noise

≤55dB

Standard

1 vacuum pump, 2 KF25 clamps, 1 KF vacuum hose
